Zendure SolarFlow 800 Pro 2

Zendure SolarFlow 800 Pro 2 – All-in-One Balcony Power Plant Storage System with 1,92 kWh & 4 MPPT

The Zendure SolarFlow 800 Pro 2 combines a high-performance microinverter, intelligent battery storage, and advanced energy management in a compact all-in-one system. With 1,92 kWh of integrated LiFePO₄ storage , four independent MPPT inputs, and a maximum PV input power of 2.640 W , the system is a particularly powerful solution for modern balcony power plants and small photovoltaic systems.

Excess solar energy is not fed unused into the public grid, but is temporarily stored in the integrated battery storage system and later made available for the user's own electricity consumption. With a grid-connected AC output of up to 800 W and intelligent HEMS energy management, the self-consumption of self-generated solar power can be significantly increased.

All-in-one: Storage and microinverter in one device

The SolarFlow 800 Pro 2 combines battery storage, power electronics, and microinverter in a single device. This significantly reduces installation effort and requires fewer separate components.

With an integrated storage capacity of 1.920 Wh, solar energy generated during the day can be stored and used again in the evening or at night. This makes the SolarFlow 800 Pro 2 particularly interesting for households that want to maximize their self-consumption of energy from their balcony power plant.

4 MPPTs and up to 2.640 W PV input power

A particular highlight of the Zendure SolarFlow 800 Pro 2 is its four independent MPPT inputs . Each input supports a PV power of up to 660 W. This allows for the connection of solar modules with a total input power of up to 2.640 W.

The four separate MPP trackers allow for particularly flexible module layout. Different orientations or partial shading of individual modules do not necessarily affect the overall PV output. Each input can individually determine its optimal operating point.

The permissible PV operating voltage range is 14 to 55 V DC . This makes the SolarFlow 800 Pro 2 compatible with a wide selection of modern solar modules.

1,92 kWh LiFePO₄ battery already integrated

The Zendure SolarFlow 800 Pro 2 already integrates a 1,92 kWh LiFePO₄ battery . Lithium iron phosphate is one of the preferred battery technologies for stationary energy storage systems due to its high cycle stability, thermal stability, and long lifespan.

Without an additional battery, the system achieves a charging and discharging power of up to 1.440 W. If the system is expanded with compatible additional batteries, charging/discharging power of up to 2.000 W is possible.

Up to 11,52 kWh storage capacity

For those who need more storage capacity later, the Zendure SolarFlow 800 Pro 2 can be expanded modularly. The system supports compatible batteries from the Zendure AB1000 and AB2000 series , including the AB1000, AB2000, AB1000S, AB2000S, and AB2000X.

Up to five additional battery modules can be added. In combination with corresponding AB2000 batteries, a total storage capacity of up to 11,52 kWh can be achieved.

800 W feed-in power for the house network

In grid-connected operation, the SolarFlow 800 Pro 2 provides a maximum continuous AC output of 800 W. This allows the generated or stored energy to be used directly for household appliances.

The major advantage of a storage system becomes particularly apparent when PV production exceeds current household consumption. Instead of releasing excess energy unused, it is stored and can be made available again at a later time.

1.000 VA off-grid output for additional power supply security

In addition to normal grid operation, the Zendure SolarFlow 800 Pro 2 features an off-grid function with up to 1.000 VA of continuous output power . This allows suitable appliances to be supplied with energy directly from the system, independent of the home's electrical grid.

This makes the SolarFlow 800 Pro 2 interesting not only for classic balcony power plants, but also, for example, for garden sheds, tool sheds or other applications where stored solar energy is to be used flexibly.

Intelligent HEMS for optimized self-consumption

The Zendure SolarFlow 800 Pro 2 works with an intelligent Home Energy Management System (HEMS) . This supports the automatic optimization of generation, storage and consumption.

This can take into account factors such as the household's energy needs, available battery capacity, and other relevant data. The goal is to use as much of the self-generated solar power as possible, either directly or at a later time, within the household.

Applications in conjunction with dynamic electricity tariffs are also possible. This allows the system to intelligently manage energy not only based on PV generation, but also taking into account times of favorable electricity procurement.

Monitoring and control via Zendure app

The Zendure app allows users to conveniently monitor important operating data and adjust settings on the energy system. The SolarFlow 800 Pro 2 supports both 2,4 GHz Wi-Fi and Bluetooth 5.0.

This allows for convenient control of energy generation, battery status and energy flows, and configuration of the system according to individual requirements.

IP65 – designed for flexible use

The SolarFlow 800 Pro 2 features a robust housing with IP65 protection . This protects the device against dust and water jets, making it suitable for various locations.

The recommended operating temperature range is between -20 °C and +55 °C . The battery can be charged at temperatures between 0 °C and +55 °C.

Technical specifications Zendure SolarFlow 800 Pro 2

• Manufacturer: cendura
• Product: SolarFlow 800 Pro 2
• Model: ZDA2503
• Manufacturer article number: ZDA2503-gy-eu
• EAN / GTIN: 6976552198691
• Battery technology: LiFePO₄
• Integrated storage capacity: 1.920 Wh / 1,92 kWh
• Battery voltage: 48 V DC
• PV inputs: 4 independent MPPTs
• Max. PV input power: 2.640 W (4 × 660 W)
• Max. PV input voltage: 55 V DC
• PV operating voltage range: 14-55V DC
• Max. PV input current: 18 A per input
• Max. PV short-circuit current: 22,5 A per input
• Max. continuous AC power output, grid-connected: 800 W
• Max. AC continuous power off-grid: 1.000 VA
• Max. AC input power: 1.000 W
• AC voltage / frequency: 230 V / Hz 50
• Charging/discharging power without additional battery: up to 1.440 W
• Maximum charging/discharging power with auxiliary battery: up to 2.000 W
• Maximum storage capacity: up to 11,52 kWh
• Additional batteries: up to 5
• Communication: Wi-Fi & Bluetooth 5.0
• Protection class: IP65K
• Protection class: Class I
• Operating temperatur: -20 ° C to +55 ° C
• Dimensions: 392,7 × 236,3 × 276 mm
• Weight Approx. 22,6 kg

Who is the Zendure SolarFlow 800 Pro 2 suitable for?

The Zendure SolarFlow 800 Pro 2 is particularly suitable for users who want to build a high-performance balcony power plant with integrated battery storage. Its four MPPT inputs allow for the flexible integration of multiple solar modules, while the integrated 1,92 kWh battery stores excess solar energy for later use.

Thanks to its modular expandability, the system is suitable for both beginners and users with higher energy demands. The combination of 2.640 W PV input power, 1,92 kWh storage, 800 W AC output, and intelligent energy management makes the SolarFlow 800 Pro 2 a powerful all-in-one solution for high self-consumption rates.
